Motor Heating Oven Manufacturer, Supplier & Exporter
A motor heating oven heats complete motors and motor parts for drying, varnish baking, bearing removal or shrink-fit assembly. Strong blowers push air evenly through the chamber, so motors of different sizes heat up uniformly.
MV International motor heating ovens are available from compact cabinet sizes to walk-in rooms, in capacities to suit your motor sizes. Easy-to-use doors and controls let operators load, set the temperature and start the cycle in seconds.
Key Features of Our Motor Heating Oven
- Compact to walk-in sizes for all motor frames
- High-volume blowers for even heating
- Heavy-duty floor or trolley loading
- Temperature control up to 250°C
- Moisture and solvent exhaust
- Easy-to-operate digital controls
Motor Heating Oven Applications
- Drying motors after rewinding or flooding
- Varnish baking
- Heating motor frames for bearing or stator fitting
- Preheating before impregnation
- Service workshops and utilities
- Motor OEM production
How the Motor Heating Oven Works
The motor is placed inside and hot air is circulated around and through it. The controller holds the set temperature for drying or baking, while exhaust removes moisture and solvent vapours.
Motor Heating Oven Technical Specifications
| Size of the working chamber | As per client requirement. |
|---|---|
| Material of construction | Mild Steel, Stainless Steel 304 / 316 or any. |
| Temperature Range | Ambient to 150°C / 250°C / 400°C / 500°C. |
| Air circulation | Vertical, Horizontal or Combination. High Volume and high Velocity Airflow provides twice the air changes compared to ordinary Industrial Ovens. |
| Timer | Digital Pre-Settable with range up to 0 to 999 Minutes / Seconds |
| Paint | Enamel Paint / Epoxy Coating / Powder Coated. |
| Power supply | 230 Volts Single Phase 50Hz / 60Hz 415 Volts 3 Phase 50Hz / 60Hz |
| Heating Elements | Low wattage Incoloy sheathed heating elements / SS Tubular |
| Insulation | Ceramic Wool / Mineral Wool |
| Door Gasket | Fibreglass Rope (High Temp) / Silicone Gasket. |
| Heavy Duty Shelves / Trays | Made out of angles with wire knitted mesh or perforated sheet suitable for oven internal size will be provided along with the oven. |
| Exhaust Manual or Automatic | Automatic forced exhaust system with fresh air inlet. Manually adjustable damper with fresh air inlet. |
| Heating Media | Electric / Gas / Diesel / Steam / Thermic OIL etc. |
Optional Features
| Temperature Control | PID with or without Profile Setting (Temp Up and Down) can be provided with SSR/ SCR for high accuracy. The programming of PID can vary from 4 to 50 programmes. |
|---|---|
| Temperature Recorder | Microprocessor chip-based paper less, Multi-Stage Temp. Indicator cum Recorder. |
| PLC With HMI | PLC can be provided for automation and integration of whole system, data feeding, process display, and fault indication can be seen in HMI. |
| SCADA System | High quality integration and controlling system from one point can be done with SCADA. |
| Door | A. Door interlocking system will switch off the blower and the heating system if the oven doors are open B. Doors on both ends C. Vertical lift door |
| Fumes Outlet | Forced exhaust blower |
| Windows and lights | A. Viewing window B. Interior lights and Access ports for calibration C. Oven on switch- Illuminated D. Heat on switch- Illuminated |
| Timer and Alarm | A. 24/7 timer B. Audible/visual alarm indicators |
Motor Heating Oven Manufacturer, Supplier & Exporter
Motor Heating Oven Manufacturer in India
We manufacture the motor heating oven at our factory in M.I.E. Bahadurgarh, Haryana, using CNC-cut sheet metal, mineral or ceramic wool insulation and reliable control gear. As an experienced motor heating oven manufacturer, we run every oven at its working temperature (up to 500°C) before dispatch and share the test results with you.
Motor Heating Oven Supplier
As a motor heating oven supplier, we deliver across India, including Delhi NCR, Haryana, Punjab, Uttar Pradesh, Gujarat, Maharashtra, Tamil Nadu, Karnataka, Telangana and West Bengal. Typical buyers are motor repair workshops, OEMs and industrial maintenance teams. We handle site installation and commissioning, operator training, spares and after-sales service.
Motor Heating Oven Exporter
As a motor heating oven exporter, we have delivered heating equipment to more than 50 countries, including United Kingdom, Nepal, Nigeria, Egypt and Indonesia. Each export order includes voltage and frequency matching, CE-style safety interlocks on request, export-worthy packing, and remote or on-site commissioning support.
Why Buy from MV International?
- In-house design and manufacturing since 1989, ISO 9001:2015 certified
- Custom chamber sizes, temperatures up to 500°C and electric, gas, diesel or steam heating
- Uniform air flow with high-volume blowers and PID/PLC temperature control
- Every oven is trial-run and tested before dispatch
- Installation, training, spares and after-sales service across India and abroad
Motor Heating Oven FAQs
Can I heat a complete motor in the oven?
Yes. Complete motors can be dried, provided temperature stays within the insulation and bearing grease limits.
What size motors can be handled?
From fractional-HP motors to large HT motors. The oven is sized and loaded to suit.
Do you have ovens for HT/LT motors?
Yes. See our electric oven for HT/LT motors.
How much does a Motor Heating Oven cost?
A motor heating oven is built to order, so the cost depends on the working size, temperature range, heating method and options such as PLC control or a temperature recorder. Send us your requirement on the enquiry page or call +91-9718290000 for a quick, no-obligation quotation.
Can you supply the Motor Heating Oven to buyers abroad?
Yes. Along with supplying all over India, we export the motor heating oven to the Middle East, Africa, Asia, Europe and the Americas. Ovens are built for your local power supply and shipped with complete documentation and commissioning support.
Need a motor heating oven? Send your part size, process details and production rate to sales@industrialoven.com or call +91 97182 90000. Our engineers will suggest the right model and send a quotation.
