Heat Shrink Oven Manufacturer, Supplier & Exporter
A heat shrink oven applies controlled heat to shrink sleeves, tubing, labels and films tightly onto products. It is used for cable and wire harness sleeving, pipe-joint sleeves, rollers, bottles and packaging, wherever a tight, uniform shrink is needed without scorching.
MV International heat shrink ovens are built with robust construction, anti-corrosive finishes, easy installation and controlled energy use. Batch and conveyor (tunnel) versions are available, and each oven is tested against preset parameters before dispatch.
Key Features of Our Heat Shrink Oven
- Controlled heating for even, wrinkle-free shrinking
- Batch or conveyor tunnel designs
- Adjustable air velocity and direction
- Energy-controlled heater system
- Anti-corrosive, robust construction
- Easy installation
Heat Shrink Oven Applications
- Heat-shrink sleeves on cables and harnesses
- Pipe-joint and coating sleeves
- Shrink labels on bottles and containers
- Shrink packaging
- Roller and handle sleeving
- Electrical component insulation
How the Heat Shrink Oven Works
Products with loose sleeves or film pass through, or are placed in, the heated chamber. Hot air at the shrink temperature makes the material contract evenly onto the product, and the time or line speed is set so it shrinks fully without overheating.
Heat Shrink Oven Technical Specifications
| Size of the working chamber | As per client requirement. |
|---|---|
| Material of construction | Mild Steel, Stainless Steel 304 / 316 or any. |
| Temperature Range | Ambient to 150°C / 250°C / 400°C / 500°C. |
| Air circulation | Vertical, Horizontal or Combination. High Volume and high Velocity Airflow provides twice the air changes compared to ordinary Industrial Ovens. |
| Timer | Digital Pre-Settable with range up to 0 to 999 Minutes / Seconds |
| Paint | Enamel Paint / Epoxy Coating / Powder Coated. |
| Power supply | 230 Volts Single Phase 50Hz / 60Hz 415 Volts 3 Phase 50Hz / 60Hz |
| Heating Elements | Low wattage Incoloy sheathed heating elements / SS Tubular |
| Insulation | Ceramic Wool / Mineral Wool |
| Door Gasket | Fibreglass Rope (High Temp) / Silicone Gasket. |
| Heavy Duty Shelves / Trays | Made out of angles with wire knitted mesh or perforated sheet suitable for oven internal size will be provided along with the oven. |
| Exhaust Manual or Automatic | Automatic forced exhaust system with fresh air inlet. Manually adjustable damper with fresh air inlet. |
| Heating Media | Electric / Gas / Diesel / Steam / Thermic OIL etc. |
Optional Features
| Temperature Control | PID with or without Profile Setting (Temp Up and Down) can be provided with SSR/ SCR for high accuracy. The programming of PID can vary from 4 to 50 programmes. |
|---|---|
| Temperature Recorder | Microprocessor chip-based paper less, Multi-Stage Temp. Indicator cum Recorder. |
| PLC With HMI | PLC can be provided for automation and integration of whole system, data feeding, process display, and fault indication can be seen in HMI. |
| SCADA System | High quality integration and controlling system from one point can be done with SCADA. |
| Door | A. Door interlocking system will switch off the blower and the heating system if the oven doors are open B. Doors on both ends C. Vertical lift door |
| Fumes Outlet | Forced exhaust blower |
| Windows and lights | A. Viewing window B. Interior lights and Access ports for calibration C. Oven on switch- Illuminated D. Heat on switch- Illuminated |
| Timer and Alarm | A. 24/7 timer B. Audible/visual alarm indicators |
Heat Shrink Oven Manufacturer, Supplier & Exporter
Heat Shrink Oven Manufacturer in India
We manufacture the heat shrink oven at our factory in M.I.E. Bahadurgarh, Haryana, using CNC-cut sheet metal, mineral or ceramic wool insulation and reliable control gear. As an experienced heat shrink oven manufacturer, we run every oven at its working temperature (up to 500°C) before dispatch and share the test results with you.
Heat Shrink Oven Supplier
As a heat shrink oven supplier, we deliver across India, including Delhi NCR, Haryana, Punjab, Uttar Pradesh, Gujarat, Maharashtra, Tamil Nadu, Karnataka, Telangana and West Bengal. Typical buyers are cable, packaging, pipe-coating and electrical manufacturers. We handle site installation and commissioning, operator training, spares and after-sales service.
Heat Shrink Oven Exporter
As a heat shrink oven exporter, we have delivered heating equipment to more than 50 countries, including Qatar, United States, Bangladesh, Sri Lanka and Kenya. Each export order includes voltage and frequency matching, CE-style safety interlocks on request, export-worthy packing, and remote or on-site commissioning support.
Why Buy from MV International?
- In-house design and manufacturing since 1989, ISO 9001:2015 certified
- Custom chamber sizes, temperatures up to 500°C and electric, gas, diesel or steam heating
- Uniform air flow with high-volume blowers and PID/PLC temperature control
- Every oven is trial-run and tested before dispatch
- Installation, training, spares and after-sales service across India and abroad
Heat Shrink Oven FAQs
What temperature is needed for heat shrinking?
Most heat-shrink polyolefin tubing shrinks at about 90-135°C. Films and sleeves vary, so we design for your material.
Batch or tunnel heat shrink oven?
Tunnels suit high-volume packaging lines. Batch ovens suit mixed parts and lower volumes.
Can the oven handle long cable harnesses?
Yes. Racks or conveyors are designed for your product length.
What is the price of a Heat Shrink Oven?
The price of a heat shrink oven depends on chamber size, maximum temperature, heating media (electric, gas, diesel or steam), material of construction and the control system. Share your load details, process temperature and cycle time, and MV International will send a detailed quotation, usually within 24 hours.
Can you supply the Heat Shrink Oven to buyers abroad?
Yes. Along with supplying all over India, we export the heat shrink oven to the Middle East, Africa, Asia, Europe and the Americas. Ovens are built for your local power supply and shipped with complete documentation and commissioning support.
Need a heat shrink oven? Send your part size, process details and production rate to sales@industrialoven.com or call +91 97182 90000. Our engineers will suggest the right model and send a quotation.
