Infrared Conveyor Oven Manufacturer, Supplier & Exporter
An infrared conveyor oven combines a conveyor with infrared emitters that heat the coating or surface directly. Because IR energy is absorbed straight into the product, cure times can be up to 75% shorter than in a convection oven, and the oven needs far less floor space.
MV International infrared conveyor ovens use short-wave or medium-wave IR lamps arranged in controlled zones. The conveyor and oven length are designed for your parts and line speed.
Key Features of Our Infrared Conveyor Oven
- Short-wave or medium-wave IR emitters
- Up to 75% shorter cure times than convection
- Compact footprint
- Zone-wise SCR power control
- Belt or chain conveyor with variable speed
- Instant on/off with no long warm-up
Infrared Conveyor Oven Applications
- Powder coating gelling and curing
- Paint and lacquer drying
- Screen-printing ink drying
- Adhesive activation
- Plastic preheating
- Drying after washing
How the Infrared Conveyor Oven Works
As parts move on the conveyor, IR emitters above and/or below radiate energy onto them. Zone power and conveyor speed together set the heat delivered. Short-wave lamps respond in seconds, so the oven can follow product changes quickly.
Infrared Conveyor Oven Technical Specifications
| Application | For AC Coils, Painting, Automobiles, Metal Industry, Furniture etc. |
|---|---|
| Size of the working chamber | As per client requirement. |
| Material of Construction | Mild Steel, Stainless Steel 304 / 316 or any. |
| Temperature Range | Ambient to 150°C / 250°C / 400°C / 500°C |
| Air circulation | Vertical, Horizontal or Combination. |
| Timer | Digital Pre-Settable with range up to 0 to 999 Minutes / Seconds. |
| Power supply | 415 Volts 3 Phase 50Hz / 60Hz. |
| Heating Elements | Low wattage Incoloy sheathed heating elements / SS Tubular. |
| Insulation | Ceramic Wool / Mineral Wool |
| Height Adjustable Door | Both sides on request. |
| AIR Curtains | Both Sides on request for minimise the heat loss. |
| Exhaust Manual or Automatic | Automatic forced exhaust system with fresh air inlet. Manually adjustable damper with fresh air inlet. |
| Heating Media | Electric / Gas / Diesel / Thermic OIL etc. |
Infrared Conveyor Oven Manufacturer, Supplier & Exporter
Infrared Conveyor Oven Manufacturer in India
As a infrared conveyor oven manufacturer in India since 1989, MV International designs and builds every unit at our own works in Bahadurgarh, Haryana, close to Delhi NCR. Our engineers size the chamber, heater load and air-flow pattern to your actual load, so the oven reaches 500°C evenly and holds it within a tight band. Every infrared conveyor oven is assembled, wired and trial-run at our plant before dispatch.
Infrared Conveyor Oven Supplier
MV International supplies the infrared conveyor oven to coating, printing, plastic and automotive component makers all over India. Industrial clusters we serve regularly include Gurugram, Faridabad, Noida, Ludhiana, Ahmedabad, Vadodara, Pune, Chennai, Bengaluru, Hyderabad and Kolkata. With every oven we provide a manual, wiring diagram, spares list and quick service support.
Infrared Conveyor Oven Exporter
Overseas buyers source the infrared conveyor oven from us because we combine Indian manufacturing costs with export-quality construction. Regular destinations include UAE, Qatar, United States, Bangladesh and Sri Lanka. We build to your local power supply, quote FOB or CIF, and supply documentation, spares and remote support.
Why Buy from MV International?
- In-house design and manufacturing since 1989, ISO 9001:2015 certified
- Custom chamber sizes, temperatures up to 500°C and electric, gas, diesel or steam heating
- Uniform air flow with high-volume blowers and PID/PLC temperature control
- Every oven is trial-run and tested before dispatch
- Installation, training, spares and after-sales service across India and abroad
Infrared Conveyor Oven FAQs
How much faster is infrared curing?
For suitable coatings and parts, IR can shorten curing time by up to 75% compared with convection.
Can IR cure complex shapes?
IR works best on surfaces the emitters can 'see'. For complex shapes, a hybrid IR + convection oven is recommended.
Do you also make batch IR ovens?
Yes. See our infrared oven.
What is the price of a Infrared Conveyor Oven?
The price of a infrared conveyor oven depends on chamber size, maximum temperature, heating media (electric, gas, diesel or steam), material of construction and the control system. Share your load details, process temperature and cycle time, and MV International will send a detailed quotation, usually within 24 hours.
Do you export the Infrared Conveyor Oven outside India?
Yes. MV International is an experienced infrared conveyor oven exporter. We ship to the UAE, Saudi Arabia, Qatar, Oman, Africa, South-East Asia, Europe and the Americas, with voltage and frequency matched to your country and seaworthy export packing.
Need a infrared conveyor oven? Send your part size, process details and production rate to sales@industrialoven.com or call +91 97182 90000. Our engineers will suggest the right model and send a quotation.
