Industrial Hot Air Oven Manufacturer, Supplier & Exporter
An industrial hot air oven uses electrically heated, circulated air for drying, baking, curing and dry-heat sterilisation. It is used in factories, laboratories, hospitals, research institutes and government organisations, wherever reliable, uniform heat is needed.
MV International manufactures hot air ovens in many sizes and temperature ratings, and customises them to the user's needs. Application-based design and quality components make them sturdy and dependable.
Key Features of Our Industrial Hot Air Oven
- Forced hot-air circulation
- Temperatures up to 250-300°C
- SS or aluminised interiors with adjustable shelves
- Digital PID controller, timer and safety thermostat
- Sizes from laboratory to industrial
- Custom sizes and specifications
Industrial Hot Air Oven Applications
- Dry-heat sterilisation of instruments and glassware
- Drying of samples and materials
- Baking and curing
- Industrial component drying
- Hospital and pharma use
- Research and educational labs
How the Industrial Hot Air Oven Works
Air heated by electric elements is circulated by a fan through the chamber. The controller maintains the set temperature, and the timer controls the drying or sterilising period.
Industrial Hot Air Oven Technical Specifications
| Size of the working chamber | As per client requirement. |
|---|---|
| Material of construction | Mild Steel, Stainless Steel 304 / 316 or any. |
| Temperature Range | Ambient to 150°C / 250°C / 400°C / 500°C. |
| Air circulation | Vertical, Horizontal or Combination. High Volume and high Velocity Airflow provides twice the air changes compared to ordinary Industrial Ovens. |
| Timer | Digital Pre-Settable with range up to 0 to 999 Minutes / Seconds |
| Paint | Enamel Paint / Epoxy Coating / Powder Coated. |
| Power supply | 230 Volts Single Phase 50Hz / 60Hz 415 Volts 3 Phase 50Hz / 60Hz |
| Heating Elements | Low wattage Incoloy sheathed heating elements / SS Tubular |
| Insulation | Ceramic Wool / Mineral Wool |
| Door Gasket | Fibreglass Rope (High Temp) / Silicone Gasket. |
| Heavy Duty Shelves / Trays | Made out of angles with wire knitted mesh or perforated sheet suitable for oven internal size will be provided along with the oven. |
| Exhaust Manual or Automatic | Automatic forced exhaust system with fresh air inlet. Manually adjustable damper with fresh air inlet. |
| Heating Media | Electric / Gas / Diesel / Steam / Thermic OIL etc. |
Optional Features
| Temperature Control | PID with or without Profile Setting (Temp Up and Down) can be provided with SSR/ SCR for high accuracy. The programming of PID can vary from 4 to 50 programmes. |
|---|---|
| Temperature Recorder | Microprocessor chip-based paper less, Multi-Stage Temp. Indicator cum Recorder. |
| PLC With HMI | PLC can be provided for automation and integration of whole system, data feeding, process display, and fault indication can be seen in HMI. |
| SCADA System | High quality integration and controlling system from one point can be done with SCADA. |
| Door | A. Door interlocking system will switch off the blower and the heating system if the oven doors are open B. Doors on both ends C. Vertical lift door |
| Fumes Outlet | Forced exhaust blower |
| Windows and lights | A. Viewing window B. Interior lights and Access ports for calibration C. Oven on switch- Illuminated D. Heat on switch- Illuminated |
| Timer and Alarm | A. 24/7 timer B. Audible/visual alarm indicators |
Industrial Hot Air Oven Manufacturer, Supplier & Exporter
Industrial Hot Air Oven Manufacturer in India
As a industrial hot air oven manufacturer in India since 1989, MV International designs and builds every unit at our own works in Bahadurgarh, Haryana, close to Delhi NCR. Our engineers size the chamber, heater load and air-flow pattern to your actual load, so the oven reaches 300°C evenly and holds it within a tight band. Every industrial hot air oven is assembled, wired and trial-run at our plant before dispatch.
Industrial Hot Air Oven Supplier
MV International supplies the industrial hot air oven to industries, laboratories, hospitals and research institutions all over India. Industrial clusters we serve regularly include Gurugram, Faridabad, Noida, Ludhiana, Ahmedabad, Vadodara, Pune, Chennai, Bengaluru, Hyderabad and Kolkata. With every oven we provide a manual, wiring diagram, spares list and quick service support.
Industrial Hot Air Oven Exporter
Overseas buyers source the industrial hot air oven from us because we combine Indian manufacturing costs with export-quality construction. Regular destinations include Nigeria, Egypt, Indonesia, Saudi Arabia and Oman. We build to your local power supply, quote FOB or CIF, and supply documentation, spares and remote support.
Why Buy from MV International?
- In-house design and manufacturing since 1989, ISO 9001:2015 certified
- Custom chamber sizes, temperatures up to 500°C and electric, gas, diesel or steam heating
- Uniform air flow with high-volume blowers and PID/PLC temperature control
- Every oven is trial-run and tested before dispatch
- Installation, training, spares and after-sales service across India and abroad
Industrial Hot Air Oven FAQs
What temperature is used for hot air sterilisation?
Dry-heat sterilisation is typically done at 160°C for 2 hours or 170-180°C for shorter times.
Is a hot air oven the same as an air circulation oven?
They are very similar. See also our air circulation oven.
Can you make a large industrial hot air oven?
Yes. We build hot air ovens from bench size to walk-in rooms.
How much does a Industrial Hot Air Oven cost?
A industrial hot air oven is built to order, so the cost depends on the working size, temperature range, heating method and options such as PLC control or a temperature recorder. Send us your requirement on the enquiry page or call +91-9718290000 for a quick, no-obligation quotation.
Can you supply the Industrial Hot Air Oven to buyers abroad?
Yes. Along with supplying all over India, we export the industrial hot air oven to the Middle East, Africa, Asia, Europe and the Americas. Ovens are built for your local power supply and shipped with complete documentation and commissioning support.
Need a industrial hot air oven? Send your part size, process details and production rate to sales@industrialoven.com or call +91 97182 90000. Our engineers will suggest the right model and send a quotation.
