Moisture Drying Oven Manufacturer, Supplier & Exporter
A moisture drying oven removes absorbed water from components, raw materials and finished goods by combining controlled heat with constant fresh-air exchange. MV International builds moisture drying ovens with a high-volume re-circulation blower and an adjustable exhaust, so the moist air is pushed out continuously and drying time is kept short.
Moisture affects many processes. It causes porosity in castings, low insulation resistance in motors and transformers, and lumps in powders. It also leads to defects in moulded plastics and coated parts. Our ovens remove this moisture evenly without overheating sensitive parts.
Key Features of Our Moisture Drying Oven
- Fresh-air inlet and motorised or manual exhaust damper to expel humid air
- Uniform horizontal or vertical air flow with high-velocity blower
- Temperature range ambient to 150/250/400°C, PID controlled
- SS or aluminium-coated inner chamber that resists corrosion from moisture
- Perforated trays or trolleys for maximum air contact with the load
- Optional humidity-based exhaust control and digital temperature recorder
Moisture Drying Oven Applications
- Drying of electric motor and transformer windings
- Removing moisture from plastic granules before moulding
- Drying of powders, chemicals and pigments
- Dehydrating foundry cores and moulds
- Drying washed or phosphated metal parts
- Drying electronic assemblies and PCBs
- Moisture removal from insulation materials
- Drying ceramic and refractory items
How the Moisture Drying Oven Works
Air heated by electric elements is circulated through the chamber by a blower. As it picks up moisture from the load, part of the air is continuously exhausted while fresh air enters through a calibrated inlet. This keeps the humidity inside the oven low, so water keeps evaporating from the parts. The controller holds the set temperature, and a timer ends the cycle once the load is fully dry.
Moisture Drying Oven Technical Specifications
| Size of the working chamber | As per client requirement. |
|---|---|
| Material of construction | Mild Steel, Stainless Steel 304 / 316 or any. |
| Temperature Range | Ambient to 150°C / 250°C / 400°C / 500°C. |
| Air circulation | Vertical, Horizontal or Combination. High Volume and high Velocity Airflow provides twice the air changes compared to ordinary Industrial Ovens. |
| Timer | Digital Pre-Settable with range up to 0 to 999 Minutes / Seconds |
| Paint | Enamel Paint / Epoxy Coating / Powder Coated. |
| Power supply | 230 Volts Single Phase 50Hz / 60Hz 415 Volts 3 Phase 50Hz / 60Hz |
| Heating Elements | Low wattage Incoloy sheathed heating elements / SS Tubular |
| Insulation | Ceramic Wool / Mineral Wool |
| Door Gasket | Fibreglass Rope (High Temp) / Silicone Gasket. |
| Heavy Duty Shelves / Trays | Made out of angles with wire knitted mesh or perforated sheet suitable for oven internal size will be provided along with the oven. |
| Exhaust Manual or Automatic | Automatic forced exhaust system with fresh air inlet. Manually adjustable damper with fresh air inlet. |
| Heating Media | Electric / Gas / Diesel / Steam / Thermic OIL etc. |
Optional Features
| Temperature Control | PID with or without Profile Setting (Temp Up and Down) can be provided with SSR/ SCR for high accuracy. The programming of PID can vary from 4 to 50 programmes. |
|---|---|
| Temperature Recorder | Microprocessor chip-based paper less, Multi-Stage Temp. Indicator cum Recorder. |
| PLC With HMI | PLC can be provided for automation and integration of whole system, data feeding, process display, and fault indication can be seen in HMI. |
| SCADA System | High quality integration and controlling system from one point can be done with SCADA. |
| Door | A. Door interlocking system will switch off the blower and the heating system if the oven doors are open B. Doors on both ends C. Vertical lift door |
| Fumes Outlet | Forced exhaust blower |
| Windows and lights | A. Viewing window B. Interior lights and Access ports for calibration C. Oven on switch- Illuminated D. Heat on switch- Illuminated |
| Timer and Alarm | A. 24/7 timer B. Audible/visual alarm indicators |
Moisture Drying Oven Manufacturer, Supplier & Exporter
Moisture Drying Oven Manufacturer in India
MV International is an ISO 9001:2015 certified moisture drying oven manufacturer with more than 35 years of experience in industrial heating. Fabrication, insulation, electrical panel building and testing are done in-house at Bahadurgarh, Haryana, which lets us control quality and delivery time. Each moisture drying oven is built to your load, process temperature (up to 500°C) and floor space rather than picked from a catalogue.
Moisture Drying Oven Supplier
Looking for a reliable moisture drying oven supplier? We have supplied ovens to motor rewinding shops, transformer makers, plastic moulders, chemical plants and foundries and to OEMs and job shops in every major industrial state of India. You get one point of contact for design, manufacturing, delivery, installation and service, with heaters, blowers and controllers available from stock.
Moisture Drying Oven Exporter
MV International is also an established moisture drying oven exporter. We ship to the Middle East, Africa, South and South-East Asia, Europe and the Americas, including Saudi Arabia, Oman, United Kingdom, Nepal and Nigeria. Export ovens are built for the local supply voltage and frequency (50 Hz or 60 Hz), packed in seaworthy wooden crates and sent with complete documentation.
Why Buy from MV International?
- In-house design and manufacturing since 1989, ISO 9001:2015 certified
- Custom chamber sizes, temperatures up to 500°C and electric, gas, diesel or steam heating
- Uniform air flow with high-volume blowers and PID/PLC temperature control
- Every oven is trial-run and tested before dispatch
- Installation, training, spares and after-sales service across India and abroad
Moisture Drying Oven FAQs
How long does a moisture drying oven take to dry parts?
Drying time depends on the material, its starting moisture level, load thickness and temperature. Most component drying cycles run from 1 to 8 hours. We size the heaters and exhaust so the cycle meets your production rate.
Why is exhaust important in a moisture drying oven?
Water vapour must leave the chamber. Without controlled exhaust, the air inside becomes saturated and drying slows down. Our ovens use a fresh-air inlet and exhaust damper to keep humidity low.
Can the oven dry heat-sensitive materials?
Yes. The PID controller can hold low temperatures such as 50-80°C accurately, and air velocity can be adjusted for light or delicate materials.
How much does a Moisture Drying Oven cost?
A moisture drying oven is built to order, so the cost depends on the working size, temperature range, heating method and options such as PLC control or a temperature recorder. Send us your requirement on the enquiry page or call +91-9718290000 for a quick, no-obligation quotation.
Do you export the Moisture Drying Oven outside India?
Yes. MV International is an experienced moisture drying oven exporter. We ship to the UAE, Saudi Arabia, Qatar, Oman, Africa, South-East Asia, Europe and the Americas, with voltage and frequency matched to your country and seaworthy export packing.
Need a moisture drying oven? Send your part size, process details and production rate to sales@industrialoven.com or call +91 97182 90000. Our engineers will suggest the right model and send a quotation.
