Air Circulation Oven Manufacturer, Supplier & Exporter
An air circulation oven (hot air oven) uses a blower to move heated air continuously through the chamber, giving much more uniform temperature and faster heating than natural-convection ovens. It is one of the most versatile pieces of thermal equipment and is used for drying, baking, annealing, curing and sterilising.
MV International air circulation ovens work from 50°C up to 300°C and are widely used in pharmaceutical, electronics, textile and general manufacturing. They are also used in hospitals and laboratories for drying glassware and sterilising instruments.
Key Features of Our Air Circulation Oven
- Forced hot-air circulation for uniform temperature
- Temperature range 50-300°C
- SS or aluminised inner chamber with adjustable shelves
- Digital PID controller, timer and safety thermostat
- Fresh-air inlet and exhaust for moisture removal
- Sizes from laboratory to production scale
Air Circulation Oven Applications
- Drying glassware and packaging items
- Sterilisation of instruments
- Drying and annealing components
- Curing coatings and adhesives
- Moisture removal from materials
- Textile and fibre testing
- Electronics baking
- Research and laboratory work
How the Air Circulation Oven Works
A motor-driven blower draws air over the heaters and pushes it through the chamber, around the load and back again. This forced movement equalises temperature everywhere in the chamber, and the PID controller keeps it at the set point.
Air Circulation Oven Technical Specifications
| Size of the working chamber | As per client requirement. |
|---|---|
| Material of construction | Mild Steel, Stainless Steel 304 / 316 or any. |
| Temperature Range | Ambient to 150°C / 250°C / 400°C / 500°C. |
| Air circulation | Vertical, Horizontal or Combination. High Volume and high Velocity Airflow provides twice the air changes compared to ordinary Industrial Ovens. |
| Timer | Digital Pre-Settable with range up to 0 to 999 Minutes / Seconds |
| Paint | Enamel Paint / Epoxy Coating / Powder Coated. |
| Power supply | 230 Volts Single Phase 50Hz / 60Hz 415 Volts 3 Phase 50Hz / 60Hz |
| Heating Elements | Low wattage Incoloy sheathed heating elements / SS Tubular |
| Insulation | Ceramic Wool / Mineral Wool |
| Door Gasket | Fibreglass Rope (High Temp) / Silicone Gasket. |
| Heavy Duty Shelves / Trays | Made out of angles with wire knitted mesh or perforated sheet suitable for oven internal size will be provided along with the oven. |
| Exhaust Manual or Automatic | Automatic forced exhaust system with fresh air inlet. Manually adjustable damper with fresh air inlet. |
| Heating Media | Electric / Gas / Diesel / Steam / Thermic OIL etc. |
Optional Features
| Temperature Control | PID with or without Profile Setting (Temp Up and Down) can be provided with SSR/ SCR for high accuracy. The programming of PID can vary from 4 to 50 programmes. |
|---|---|
| Temperature Recorder | Microprocessor chip-based paper less, Multi-Stage Temp. Indicator cum Recorder. |
| PLC With HMI | PLC can be provided for automation and integration of whole system, data feeding, process display, and fault indication can be seen in HMI. |
| SCADA System | High quality integration and controlling system from one point can be done with SCADA. |
| Door | A. Door interlocking system will switch off the blower and the heating system if the oven doors are open B. Doors on both ends C. Vertical lift door |
| Fumes Outlet | Forced exhaust blower |
| Windows and lights | A. Viewing window B. Interior lights and Access ports for calibration C. Oven on switch- Illuminated D. Heat on switch- Illuminated |
| Timer and Alarm | A. 24/7 timer B. Audible/visual alarm indicators |
Air Circulation Oven Manufacturer, Supplier & Exporter
Air Circulation Oven Manufacturer in India
MV International is an ISO 9001:2015 certified air circulation oven manufacturer with more than 35 years of experience in industrial heating. Fabrication, insulation, electrical panel building and testing are done in-house at Bahadurgarh, Haryana, which lets us control quality and delivery time. Each air circulation oven is built to your load, process temperature (up to 300°C) and floor space rather than picked from a catalogue.
Air Circulation Oven Supplier
Looking for a reliable air circulation oven supplier? We have supplied ovens to pharmaceutical, electronics, textile, hospital and laboratory users and to OEMs and job shops in every major industrial state of India. You get one point of contact for design, manufacturing, delivery, installation and service, with heaters, blowers and controllers available from stock.
Air Circulation Oven Exporter
MV International is also an established air circulation oven exporter. We ship to the Middle East, Africa, South and South-East Asia, Europe and the Americas, including Saudi Arabia, Oman, United Kingdom, Nepal and Nigeria. Export ovens are built for the local supply voltage and frequency (50 Hz or 60 Hz), packed in seaworthy wooden crates and sent with complete documentation.
Why Buy from MV International?
- In-house design and manufacturing since 1989, ISO 9001:2015 certified
- Custom chamber sizes, temperatures up to 500°C and electric, gas, diesel or steam heating
- Uniform air flow with high-volume blowers and PID/PLC temperature control
- Every oven is trial-run and tested before dispatch
- Installation, training, spares and after-sales service across India and abroad
Air Circulation Oven FAQs
What is the difference between an air circulation oven and a hot air oven?
The terms are often used interchangeably. Both use hot air, but 'air circulation' highlights the forced blower circulation that gives better uniformity.
Can it be used for sterilisation?
Yes. Dry-heat sterilisation is typically done at 160-180°C, which our air circulation ovens reach easily.
Do you make forced air circulation ovens for heavier loads?
Yes. See our forced air circulation oven for production use.
How much does a Air Circulation Oven cost?
A air circulation oven is built to order, so the cost depends on the working size, temperature range, heating method and options such as PLC control or a temperature recorder. Send us your requirement on the enquiry page or call +91-9718290000 for a quick, no-obligation quotation.
Can you supply the Air Circulation Oven to buyers abroad?
Yes. Along with supplying all over India, we export the air circulation oven to the Middle East, Africa, Asia, Europe and the Americas. Ovens are built for your local power supply and shipped with complete documentation and commissioning support.
Need a air circulation oven? Send your part size, process details and production rate to sales@industrialoven.com or call +91 97182 90000. Our engineers will suggest the right model and send a quotation.
